KIP > Digital KIP

KIP 2000

The KIP Starprint 2000 family of machines used the KIP 2000 print engine as the base component of a highly versatile, mix and match system of features and attributes. As a stand alone printer, the Starprint 2000 can be installed in a one two or three roll configuration. KIP offers a choice of three scanners that can be attached to the 2000 print engine, based on the scanning speed required for an individual application. The principal shortcoming of the 2000 family is that it is placed in "point of use" applications where the 2000 is simply "not enough gun" for the job. If you plan to produce more than 4,000 square feet of print per month, you need to upgrade to the more robust KIP Starprint 6000.
[]
2000 Series Printer Specifications

Technology

LED Printer with KIP HDP Print Technology

Dot Size

.0025"

One Pixel Line

.0025"

DPI

400 x 400

Speed

4 D' size prints per min, 2.0" per sec

Media

1 roll version-Starprint 2001, 2051 STF

Supply

2 roll version-Starprint 2002, 2052 STF

3 roll version-Starprint 2003, 2053 STF

Media Tray

50 E' sized prints

Warm-up

Instant from standby

<4 minutes from startup

Output

Minimum:8.5" x 11"

Maximum: 36" x 100+'

Media Types

Bond 16-20lb, Film 3 mil., Vellum 16-20 lb

Dimensions

52" (W) x 25" (D) x 41" (H)

Weight

420 lbs. (1 roll version)

450 lbs. (2 roll version)

480 lbs. (3 roll version)

Power

Standby 604 W

Consumption

Printing 1205 W

Electrical Requirements

120V, 20 Amps

Safety Approvals

UL, CSA, FCC Class A

Powerprint Embedded Controller

Platform

KIP Powerprint software with Windows XP

Network

TCP/IP, NetBEUI (smb), Novell

Protocols

(IPX/SPX), LPR, LPD

File Formats

HPGL, HP-RTL, Calcomp 906/907,

CALS Group 4, TIFF Group 4, PCX,

Interpgraph CIT/TG4, Versatec Color

Graphics (VCGL), Uncompressed

Grayscale TIFF, TIFF Packbits, IBM IOCA,

EDMICS, TLC (KIP), PNG, JPEG

Optional

ATA Complaint CGM

File Formats

Postscript level 3 for EPS, PS, and PDF

Technology

Dual CCD Camera System with KIP

Real Time Thresholding Technology

Optical Resolution

400 x 400 DPI

Speed

  • 2050STF:

  • Scan Speed: 2.0" per sec @ 400 DPI

  • 4.0" per sec @ 200 DPI

  • 2080STF:

  • Scan Speed: 3.2" per sec @ 400 DPI

  • 6.4" per sec @ 200 DPI

  • 2120STF:

  • Scan Speed: 4.8" per sec @ 400 DPI

  • 9.6" per sec @ 200 DPI

  • 2160STF:

  • Scan Speed: 6.4" per sec @ 400 DPI

  • 12.8" per sec @ 200 DPI

Copy Scale

24%-400%, adjustable in 0.1%

increments and programmable steps,

independent X and Y axis zoom

Scan-to-File

5%-3600%, adjustable in 1% increments

Scale and programmed steps

Original Feed

Face down, center aligned

Originals

8.5" - 36" in width, 8.5 - 100+' in length

Exposure

KIP Real Time Thresholding Technology,

Controls

Automatic speckle and Background

Removal, Line Sharpness Adjustments

Scan Modes

Line, Line/Photo, Photo

Input Modes

Single sheet or sets, Set collation,

processing, and editing with

Insert/replace/delete sheets

On-Board Set

576 MB, upgradeable up to 1024 MB

Copy Memory

Set Copy, Collated Set, Sorted Set,

Nested printing, Continuous printing

Interrupt

Interrupt set or programmed job for

urgent network printing or copying

KIP 2900

Good solid two roll machine with a proven track record. At three "D's" per minute output this unit will not set any speed records but it is ideal for small offices that require plotting capability incorporated with the engineering copier functions of scan to print, reduction and enlargement and multiple copy plus scan to file archival capability.
[]
Scan to Print  Yes
Plot Yes
Scan to File  Yes

Printer

Minimum Output 8-1/2" X 11"
Maximum Output 36" X 20'
Feet per Minute 8
Copies Per Minute  3 "D" Size
Number of Rolls 2
Manual By-pass Yes
Multiple Copies 1 - 99
Zoom Capability 43% to 200%
Accuracy .1%
Thick or Solid Originals  ?
Collating Capability None
Photoreceptor Type OPC
Toning System Toner & Developer
Reproduction Quality of Solids Excellent
Reproduction Quality of Line Work  Excellent
Reproduction of Halftones Fair
Other Features -

Scanner

Minimum Input 8-1/2" X 11"
Maximum Input 36" X 50'
Resolution 400 dpi Maximum
Speed 8 fpm at 400 dpi
Formats PCX, CALS G4, TIFF G4, TIFF, PACKBITS

Other

Price Range at Introduction Aprox. $35,000
Equipment Manufactured By Kip
Footprint and Height 54.5" X 20" X 46"
Weight 566 lbs.
AC Power Requirements 120V, 15A

KIP 2950

Good solid two roll machine with a proven track record. This is the same print engine used in the 2900 with a redesigned developer housing and increased speed of six "D" size prints per minute. It is ideal for small offices that require plotting capability incorporated with the engineering copier functions of scan to print, reduction and enlargement and multiple copy plus scan to file archival capability.
[]
Scan to Print  Yes
Plot No
Scan to File  No

Printer

Minimum Output 8-1/2" X 11"
Maximum Output 36" X 20'
Feet per Minute 8
Copies Per Minute  6 "D" Size
Number of Rolls 2
Manual By-pass Yes
Multiple Copies 1 - 99
Zoom Capability 43% to 200%
Accuracy .1%
Thick or Solid Originals  ?
Collating Capability None
Photoreceptor Type OPC
Toning System Toner & Developer
Reproduction Quality of Solids Excellent
Reproduction Quality of Line Work  Excellent
Reproduction of Halftones Fair
Other Features -

Scanner

Minimum Input 8-1/2" X 11"
Maximum Input 36" X 50'
Resolution 400 dpi Maximum
Speed 8 fpm at 400 dpi
Formats PCX, CALS G4, TIFF G4, TIFF, PACKBITS

Other

Price Range at Introduction Aprox. $35,000
Equipment Manufactured By Kip
Footprint and Height 54.5" X 20" X 46"
Weight 566 lbs.
AC Power Requirements 120V, 15A

KIP 4000

[]
Scan to Print  Yes
Plot Yes
Scan to File  Yes

Printer

Minimum Output 8-1/2" X 11"
Maximum Output 36" X 20'
Feet per Minute 8
Copies Per Minute  3 "D" Size
Number of Rolls 2
Manual By-pass Yes
Multiple Copies 1 - 99
Zoom Capability 43% to 200%, 5% to 3600% with Controller
Accuracy .1%
Thick or Solid Originals  ?
Collating Capability Electronic
Photoreceptor Type OPC
Toning System Toner & Developer
Reproduction Quality of Solids Excellent
Reproduction Quality of Line Work  Excellent
Reproduction of Halftones Fair
Other Features -

Scanner

Minimum Input 8-1/2" X 11"
Maximum Input 36" X 50'
Resolution 400 dpi Maximum
Speed 8 fpm at 400 dpi
Formats PCX, CALS G4, TIFF G4, TIFF, PACKBITS

Controller

Technology DSS-2 200 Mhz Pentium Processor
Controller Embedded in Hardware No
Data Formats PCX, CALS G4, TIFF G4, TIFF, PACKBITS
Memory 32 MB EDO RAM
Interfaces BCN or RJ-45
Hard Drive Size 3.1 GB
Network Card Supplied Ethernet

Other

Price Range at Introduction Aprox. $45,000
Equipment Manufactured By Kip
Footprint and Height 54.5" X 20" X 46"
Weight 566 lbs.
AC Power Requirements 120V, 15A
